Toyo Si-350-7 J450HF Plastic Injection Molding Machine

The Toyo Si-7 series is a global benchmark in all-electric injection molding. Featuring state-of-the-art servo control, it ensures fast cycle times, high repeatability, and energy savings of up to 50% compared to hydraulic injection molding machines. Ideal for those seeking productivity, stability, and quality in technical or high-volume parts.

Download Solicite um Orçamento

Technical Specifications

Thread diameter (B) (mm)

Injection stroke (mm)

270

Theoretical injection volume (cm³)

763

Maximum injection rate (cm³/s)

565

Maximum injection pressure (MPa)

201

Maximum discharge pressure (MPa)

177

Plasticizing rate (g/s)

67.7

Activation

Joint

Closing force (kN)

2744

Opening stroke (mm)

600

Min. and max. mold height (mm)

300–750

Distance between columns (mm)

730x730

Stroke length (mm)

150

External dimensions (L x W x H) (mm)

7292 x 1699 x 2058

Total power (kVA)

Total weight (tons)

13.8
