ULF 3015D 3kW Okamura Single-Table Fiber Laser Sheet Metal Cutter
ULF 3015D 3KW OKAMURA Single-Table Fiber Laser Sheet Metal Cutter
The ULF-3015D 3KW is a high-efficiency solution for the precise cutting of sheets up to 1,500 x 3,000 mm, equipped with a 3,000W fiber-optic power source that ensures the ideal balance between performance and operating costs. Its robust chassis, subjected to heat treatment for stress relief and vibration aging, ensures superior mechanical stability and positioning accuracy of ±0.05 mm. With an intuitive interface on a 19” LCD panel and an integrated optical safety curtain, this model offers agility, safety, and a repeatability of ±0.03 mm for demanding production runs.
Technical Specifications
Operating System
OKAMURAInterface
19-inch LCD panelRemote Control
Wi-Fi PendantNesting Generation
AutomaticDrawing format
DXFChange of Table
NoFast Piercing
YesFly Cutting – Flying Cutting of Thin Sheets
YesAutomatic 3-Point Sheet Identification
YesSheet metal cutting area
3000 x 1500 mmFiber Optic Laser Source
3000 WLaser Wavelength
1060–1080 nmX-axis travel
1,520 mmY-axis travel
3020 mmZ-axis travel
120 mmTable Load Capacity
800 kgApproximate Weight
3,000 kgApproximate Dimensions
4420 x 2200 x 1900 mmSupply Voltage and Frequency
Three-phase 380 V, 60 HzCarbon Steel | Maximum Thickness
16 mmCarbon Steel | Recommended Thickness
13 mmStainless Steel | Maximum Thickness
8 mmStainless Steel | Recommended Thickness
6 mmAluminum | Maximum Thickness
4 mmAluminum | Recommended Thickness
3 mmCutting assist gas
O2 / N2 / High-Pressure Compressed Air [16...20 bar]X, Y Positioning Accuracy
± 0.05 mm/mX, Y Positioning Repeatability
± 0.03 mmX, Y positioning speed
80 m/minSimultaneous positioning speed (X, Y)
100 m/minAcceleration
1.0G
